What fire code access rules affect parcel layout and road design?

Fire safety regulations directly influence how industrial parcels are laid out, accessed, and serviced by emergency vehicles. These codes are typically derived from the National Building Code of India (NBC 2016, Part 4: Fire and Life Safety) and supplemented by local fire department requirements. Compliance is critical not only for development approval but also for ensuring life safety and operational readiness.

Below are the key fire access rules that affect parcel planning and road infrastructure:

1. Minimum Road Width for Fire Appliance Movement

• Internal road width must be:

  • Minimum 6 meters for general fire access

  • 9–12 meters for industrial areas handling hazardous or flammable materials

• Turning radius: Not less than 9 to 12 meters to accommodate fire tenders and ladder trucks

• Design note: Roads must be all-weather, paved, and free of obstructions (e.g., poles, trees, parked trucks)

2. Plot Access and Emergency Reach

• Every building should be accessible on at least one side, preferably two, for fire-fighting.

• For large parcels (greater than 15m in height or more than 1500 sq m built-up area), access on all four sides is recommended.

• Maintain a minimum clear open space of 6 meters around the building or boundary for fire movement.

3. Fire Access Routes and Dead-End Avoidance

• Avoid dead-end internal roads longer than 90–150 meters without a turning facility.

• Provide T-turnarounds or cul-de-sacs with a minimum 12m diameter for easy vehicle reversal.

• Demarcate fire lanes with road markings and signage.

4. Gate and Entryway Design

• Gates accessing the parcel must have:

  • Clear opening width of 4.5 to 6 meters

  • Vertical clearance of 4.5 meters (for ladder equipment and rescue vehicles)

• Gates should open inward or be sliding to not block roadways.

5. Provisions for Fire Hydrants and Water Supply

• Locate fire hydrants along the road at intervals of 30–45 meters, as per fire load category.

• Ensure hydrants are connected to:

  • An underground or overhead fire water tank (minimum 50,000–1,00,000 liters capacity depending on use)


Pump rooms with power backup
